AG EFSPBB5 5 Micron Large Diameter Pleated Filter Cartridge

Description

PLEATED Filter cartridges for LARGE DIAMETER style housings

EFSP Series Pleated Filter Cartridge Features:

• Pleated cartridges provide increased surface area, lower pressure drop and longer service life than other cartridges.
• Cellulose-free, 100% synthetic media is washable and reusable, 5 micron and up, to reduce filter costs.
• Contains no binders or additives to breakdown which may cause foaming and filter degradation.
• Color coded end caps 2 3/4” OD.
• Individually wrapped for purity.

Specifications:
Maximum temperature 140° F
Minimum temperature 40° F
Maximum pressure 40 psid
Recommended change out 25 psid
Filter Media (1 & 5 micron) Polypropylene
Filter Media (20 & 50 micron) Polyester
Material – center tube Polypropylene
Material – end caps Molded Polyurethane
ID 1 1/6
